The Five Basic Parts of a Scuba Diving Regulator

Oceania, Micronesia, Yap, Diver with grey reef sharks, Carcharhinus amblyrhynchos

Natalie Gibb owns a dive shop in Mexico and is a PADI-certified open water scuba instructor and TDI-certified full cave diving instructor.

A scuba diving regulator is the piece of equipment that enables a diver to breathe from a scuba tank. The regulator is so named because it regulates the pressure of the air a diver breathes. The compressed air inside a scuba tank is at an extremely high pressure, which could injure a diver who tries to breathe directly from the tank, and the regulator is necessary to reduce the pressure of the compressed air to a pressure the diver can breathe.

To accomplish this, a regulator reduces air pressure in two steps, or stages–first, from the pressure in the tank to an intermediate pressure; and second, from the intermediate pressure to a pressure that the divers can safely breathe. In it’s most basic form, a scuba regulator consists of two parts: a mechanism that accomplishes the first stage of pressure reduction (called ​first stage) and a mechanism that accomplishes the second stage of pressure reduction (called second stage). However, contemporary scuba diving regulators usually incorporate a variety of additional accessories.

Basics parts of Open Water Scuba Diving Regulator

Zeagle Regulator Parts: 1. first stage 2. primary second stage 3. alternate second stage 4. submersible pressure gauge and gauge console 5. low pressure inflator hose.

Five basic parts are usually included in a standard open water scuba diving regulator.

1. First Stage
The regulator first stage attaches the regulator to the scuba tank. Remember, a diving regulator reduces the air from the scuba tank in stages as it travels from the tank to the diver. The first stage of the regulator is named for its function: it accomplishes the first stage of pressure reduction by reducing the high-pressure air in the tank to an intermediate pressure. The air travels through the low pressure (LP) regulator hoses at this intermediate pressure; however, the air at this intermediate pressure is still at too high to be breathed directly and requires further reduction.

2. Primary Second Stage
The part of the regulator that a diver puts in his mouth is called the second stage. The regulator second stage is attached to the first stage by a low-pressure hose. The name “second stage” comes from this part’s function as the second stage of pressure reduction. It takes the intermediate pressure air from the regulator hose and reduces it to ambient pressure–a pressure equivalent to the air or water pressure surrounding a diver, allowing a diver to breathe from the second stage safely.

The primary second stage is one of two second stages attached to a standard open water regulator, and it is this one that a diver normally breathes from during a dive.

3. Alternate Second Stage
The alternate second stage (also known as an alternate air source, buddy regulator, or octopus) does the exact same thing as the primary second stage: it reduces intermediate air pressure supplied by a low-pressure hose to an ambient air pressure that a diver can breathe.

The alternate second stage is a back-up, that ordinarily is not used. It enables a diver to share air from his tank with a second diver in case of an out-of-air emergency. Alternate second stages are usually bright colors, such as neon yellow, which allows them to be quickly located. As diver education and safety procedures have evolved, alternate second stages have become standard scuba diving safety gear, allowing any diver to breathe from any other diver’s tank.

4. Submersible Pressure Gauge and Gauge Console
The submersible pressure gauge (also called a pressure gauge or SPG) allows a diver to monitor the amount of air in his scuba tank so that he doesn’t run out of air underwater. The pressure gauge is connected to the regulator first stage by a high-pressure hose (HP hose) that feeds high-pressure air from the tank directly to the pressure gauge. Frequently, the console containing the pressure gauge also holds a variety of other gauges, such as a depth gauge, compass, or dive computer.

5. Low-Pressure Inflator Hose
This low-pressure hose carries intermediate-pressure air from the regulator first stage to the Buoyancy Compensator’s (BC) inflator. This allows divers to add air to the BC from the tank at the touch of the button.

Let’s look at each of these five components in greater detail.

First Stage

Parts of a Scuba Diving Regulator The basic parts of a regulator first stage: 1. first stage body 2. yoke 3. yoke screw 4. dust cap 5. port/port plug.

A scuba diving regulator first stage is the part of the regulator that accomplishes the first stage of pressure reduction, reducing the high-pressure tank air to an intermediate pressure. An open-water-style regulator first stage usually connects to four hoses–three that transport intermediate-pressure air to second stages and the buoyancy compensator’s (BC) inflator, and one that allows high-pressure air to flow directly from the tank to the submersible pressure gauge.

1. First Stage Body
This metal cylinder contains the mechanisms that reduce the high-pressure air in the scuba tank to an intermediate pressure. High-pressure air flows in one side of the first stage body; undergoes pressure reduction; then flows out through the low-pressure hoses.

2. Yoke
The regulator first stage body is held against the scuba tank’s valve through one of two methods: a yoke or a DIN fitting. This diagram illustrates a yoke fitting, also called an international fitting. The “yoke” is the metal oval that fits over the tank valve to hold the regulator in place.

3. Yoke Screw
The regulator’s yoke is equipped with a yoke screw–a metal screw that runs through the regulator yoke and tightens the regulator first stage body onto the tank. To tighten the yoke screw, the diver turns the black, plastic handle attached to the screw.

4. Dust Cap
It is extremely important that no water enters the regulator first stage body. When the first stage body is tightened onto a tank, it creates a water-tight seal to the tank valve. However, when the first stage body is disconnected from the tank, it is possible for water to enter the opening in the first stage, through which air passes from the tank to the regulator. The dust cap is a rubber cap that can be placed over the regulator first stage opening and tightened down using the regulator yoke screw. This seals closed the opening on the first stage.

5. Port/ Port Plug
Regulator first stage bodies have multiple openings, or ports, that regulator hoses can be screwed into. Usually, regulators have more ports than the standard number of hoses, which allows divers to position their hoses in a variety of configurations. These openings are called ports, and the plugs that close the regulator ports when they are not in use are called port plugs.

Primary Second Stage

Regulator second stage diagram: Parts of a Scuba Diving Regulator Parts of a regulator second stage: 1. purge button 2. ease of breathing adjustment 3. exhaust valve 4. mouthpiece.

The regulator second stage is the part of the scuba diving regulator that a diver actually breathes from. The function of the second stage is to reduce intermediate-pressure air traveling through a regulator hose to an ambient pressure (the pressure of the surrounding water) that a diver can breathe safely. A primary second stage is one of two second stages on a standard open-water-style regulator. Unless there is an emergency, a diver breathes from this primary second stage during a dive.

1. Purge Button
The purge button is located on the face of the regulator second stage. The purpose of the purge button is to flood the second stage with air, forcing water out of the second stage. Divers use the purge button when the second stage has been allowed to fill with water–for example, when a diver removes the regulator from his mouth during the regulator recovery skill.

2. Ease of Breathing Adjustment
Most regulators have a lever or knob that allows divers to adjust breathing resistance. This feature helps to prevent regulator free flow (a state when air flows rapidly out of the regulator second stage without the diver breathing from it), which typically occurs when the breathing resistance has been lowered too much. A free flow can quickly empty a tank.

Many second stage adjustments have a setting labeled “pre-dive” to help prevent free flow at the surface, and one labeled “dive” for easy breathing once underwater. As a diver descends, he can adjust the ease of breathing to compensate for the increased difficulty of breathing as he descends.

3. Exhaust Valve
The second stage exhaust valve is the plastic unit that channels exhaled air bubbles away from a diver’s face. The exhaust valve is usually located below the regulator’s mouthpiece to channel air down and to the sides. This helps to keep a diver’s field of vision clear of bubbles.

4. Mouthpiece
The mouthpiece is the part of the regulator that a diver bites down on. High-quality mouthpieces are made of silicon or soft rubber (not plastic) and come in a variety of shapes and sizes to fit divers’ mouths. Mouthpieces are removable and replaceable. A diver should check to make sure that his mouthpiece is secured to the regulator second stage with a zip tie or cable tie to ensure that it does not slide off during a dive.

Alternate Second Stage

Scuba Octopus Diagram: Parts of a Scuba Diving Regulator Parts of an alternate second stage: 1. mouthpiece 2. low pressure hose 3. purge button 4. ease of breathing adjustment.

An alternate second stage (also called an alternate air source, buddy regulator, or octopus) does exactly the same thing as a primary second stage. The alternate second stage is not intended to be used except in the case of an out-of-air emergency. A diver with an alternate second stage can allow an out-of-air diver to breathe from his tank without putting himself at risk.

1. Mouthpiece
The mouthpiece is the part of the regulator second stage that a diver bites down on. Alternate second stage mouthpieces should be a standard size to fit any diver’s mouth–not a custom mouthpiece. The idea is that any diver should be able to use the mouthpiece in an emergency.

2. Low-Pressure Hose
Low-pressure hoses (LP hoses) transport air from a regulator first stage to its second stages. An alternate second stage’s LP hose is usually longer than the LP hose attached to the primary second stage. This extra length makes it easy for an out-of-air to use an alternate second stage attached to a tank he is not wearing. The LP Hose attached to an alternate second stage is frequently a bright color, such as yellow, to make it easy to see.

3. Purge Button
The purge button on the alternate second stage has the same function as a purge button on the primary second stage–to remove water that has entered the second stage. Alternate second stage purge buttons are usually brightly colored–this one is neon yellow. The bright color makes it easy for an out-of-air diver to locate the alternate second stage in an emergency. In general, the alternate second stage should be attached to the Buoyancy Compensator (BC) or diver somewhere between the bottom of the diver’s chin and the lower corners of his rib cage.

Read Post  10 Great Places to Scuba Dive in Florida

4. Ease of Breathing Adjustment
Just like the ease of breathing adjustment on a primary second stage, the ease of breathing adjustment on an alternate second stage can be used to increase or decrease breathing resistance during a dive. If an ease-of-breathing adjustment is present, a diver should adjust it so that the breathing resistance of the alternate second stage is increased. The diver should also turn any pre-dive/ dive adjustment to “pre-dive.” The regulator will still work if needed, but this adjustment will ensure that the alternate will not free-flow during the dive.

Low-Pressure Inflator Hose

Low Pressure Hose Diagram: Parts of a Scuba Diving Regulator Parts of a low pressure inflator hose: 1. sleeve 2. attachment opening.

The low-pressure inflator hose connects a regulator first stage to a buoyancy compensator’s (BC) inflation mechanism, allowing divers to add air to the BC at the touch of a button.

1. Sleeve
The metallic sleeve encircling the outside of the low-pressure inflator hose’s connection mechanism slides back toward the hose. This sleeve must be held back to connect the hose to the BC inflator mechanism. Sleeves are usually textured to make them easier to grasp underwater. Divers planning on diving in cold water or with gloves should look for sleeves with well-defined, raised ridges that make them very easy to hold on to.

2. Attachment Opening
A diver attaches his BC’s inflator mechanism to a low-pressure inflator hose by inserting the BC inflator connection into the hose’s opening while holding back its sleeve. Low-pressure inflator hose attachment openings come in different sizes. Divers need to be sure that their inflator hose attachment will fit on to the BC inflator they plan to use.

Submersible Pressure Gauge and Console

Console diagram: Parts of a Scuba Diving Regulator Parts of a diving gauge console: 1. depth gauge 2. submersible pressure gauge.

The submersible pressure gauge (SPG, pressure gauge, or air gauge) is the gauge a diver uses to monitor the amount of air remaining in his scuba tank. It is absolutely essential in diving, for it allows divers to avoid running out of air underwater. A submersible pressure gauge is frequently grouped together with other gauges on a ​console. Some of the common gauges found in a console are depth gauges, dive computers and compasses.

1. Depth Gauge
A depth gauge has two needles to monitor two different things. A black needle indicates a diver’s current depth. A second — in this case, red — needle indicates the maximum depth a diver reaches on a given dive. The needle that indicates a dive’s maximum depth needs to be reset at the beginning of each dive.

The maximum depth needle is useful when logging dives. It is also a good idea to glance at it when ascending from a dive to confirm that the planned maximum depth has not been exceeded. Depth gauges may be in units of feet or meters. (The gauge shown above is in meters.) Most depth gauges have standard safety stop depths indicated by red lettering, making it easy for a diver to remember his safety stop. The gauge shown above has the standard safety stop depth indicated by red lines between 3 and 6 meters.

2. Submersible Pressure Gauge
The submersible pressure gauge (SPG) indicates the amount of air pressure in a scuba tank. The units of pressure may be given in bar (metric), or in psi (pounds per a square inch, imperial). A standard, aluminum 80-cubic-foot tank is full at 3000 psi or 200 bar.

Different tanks styles may be full at different pressure ratings. Most pressure gauges indicate a reserve pressure, usually beginning somewhere around 50 bar or 700 psi, in red. The reserve pressure is the amount of air pressure with which a diver should begin his ascent to avoid running out of air underwater. Be warned: this “red zone” does not indicate a good reserve pressure for every dive, and it is important to take the dive profile and plan into account when deciding on a proper reserve pressure for a dive.

Scuba Diving Regulators

How the 1st and 2nd Stages, Octopus,
Diaphragm and Ports All Work

You know you need one.

But what do you need to look for and how the heck do scuba diving regulators work anyway?

We will attempt to end the mystery here.

A scuba regulator is obviously an essential piece of scuba gear. After all, it’s the only way you will be able to breathe underwater. They look fairly complicated but the basic structure is pretty straightforward.

A scuba diving regulator all attached.

Scuba Diving Regulators:
First Stage

The first stage attaches to the scuba tank and reduces the air pressure coming from the tank.

It attaches to the top of the scuba tank, usually with a knob/screw type mechanism (see photo). Technically, this is called a yoke fitting.

Scuba diving regulator and yoke

Scuba diving regulator first stage with yoke aerial view

Scuba Diving Regulators:
Second Stage

The second stage is basically the piece of the regulator that goes in your mouth and delivers air upon demand.

It contains mechanisms that reduces the intermediate pressure in the hose (coming from the first stage) to the surrounding water pressure making it comfortable and easy to breathe.

Scuba diving regulator - first stage.

The octopus is a second stage regulator that attaches to the same first stage as your main second stage regulator. The octopus is there for a back up in case something happens to your main second stage regulator or in case your buddy (or another diver) needs it.

My scuba diving regulator.

Another piece of scuba diving regulators is the inflator hose. This connects to a port from the first stage and connects to the inflator valve on your BC. Thus when you push the valve on your BC to inflate the BC, the inflator hose will deliver air from the tank, through the hose and into the air bladder of the BC.

Well, there you have it, the nitty gritty detail of how a scuba regulator works. I hope you didn’t fall asleep out there. Actually, though, it is good to understand how a regulator works since it is such an important piece of scuba gear.

But no matter how it works, just go use those scuba diving regulators and have fun!

For more information on regs, you might want to take a look at our other pages:

Looking for other scuba equipment and accessories? Check out our picks for top dive equipment in all categories and price points.

Want to stay down longer and improve your buoyancy control and other diving skills? Our free report “Increase Your Bottom Time” along with our practical, weekly actionable tips will have you looking like a seasoned diver in no time. So come join us and see improvement on your very next dive!
(Click on the photo to join us now!)

What Is The Best Regulator for Scuba Diving?

What Is The Best Regulator for Scuba Diving

We could go on and on. Some people will swear by a certain scuba regulator brand, other will swear against that. And so we can say, to each his own.

But that would be too casual. In any case, how good a regulator you have in the bowels of the ocean is a matter of life and death!

What I am trying to say is… You cannot dive without a diving regulator! Not unless you are a daredevil freediver.

But first, what is a scuba diving regulator? As the name suggests, this dive gear is going to standardize the pressure of the air coming from the scuba tank to the diver’s lungs. Buying one is easy, or hard depending on your level of experience, that is, how many years you have been diving.

There are so many factors to consider. Hopefully, after reading this article, you will be able to choose a good dive regulator, one that will give you good value for your money and last you many dives, for many years.

Here is a video showing you how a scuba tank regulator works:

Best scuba regulators

Aqualung Core Supreme – Scuba Regulator

Aqualung Core Supreme

If you are thinking of buying a new scuba regulator or even thinking of replacing your old one, the Aqualung Core Supreme is definitely worth your consideration. This scuba diving tank regulator assures you of a superb breathing performance. This is coupled with many advanced features to ensure that you get value for your money.

This Supreme version has been particularly designed for cold water diving and it is an ideal choice for the beginner divers, the intermediate ones and even the advanced ones. This regulator is lightweight so ensuring so that you can swing into action with less bulk.

This regulator has an Auto Closure Device (ACD) that automatically closes the regulators inlet the moment it is removed from the cylinder valve. This helps to keep all the corrosive water and other contaminants out. The ACD helps in maintaining the lubrication of the regulator’s internal parts therefore ensuring that it performs at its best and that it serves you for long.

It also features a heat exchanger that absorbs any heat from the surrounding waters and dispels the cold that is generated once the gas expands. The large Venturi switch that is easily adjustable even when wearing cold-water gloves prevents any unwanted free-flow on the surface when offering a high performance at lower depths.

The mouthpiece is uniquely designed to minimize jaw fatigue and it comfortably fits perfectly into your denture attaching itself on the top of your mouth. The clamp is reusable and the lip cover protects your lips from the cold underwater temperatures.

Aqua Lung Regulator Legend – Best Diving Regulator

Aqua Lung Regulator Legend

The Aqua Lung Regulator Legend is one of the best diving regulators in the market today. It is also a product of the renowned Aqua Lung brand that is known for making highly innovative and premier quality scuba gears.

This regulator is light and compactly built and it comes with very impressive features. It features an overbalanced diaphragm in the first stage that is uniquely designed to offer an exemplary breathing performance at depth. The Auto Closure Device ensures that the corrosive water does not enter the first stage inlet and that the internal lubrication is not washed away by automatically closing when the regulator is removed from the diving cylinder valve.

The over-sizes lip shield on the second stage helps in keeping your lips warm even in cold waters. The 2HP and 4MP ports are angled for an excellent hose routing. The environmental dry system helps in keeping water out of the main spring chamber therefore preventing any ice buildup and locks out any silt or contamination.

The innovative Master Breathing System (MBS) enables you to adjust the breathing performance of your regulator by controlling the direction of the air and by changing the opening effort. The Comfo-Bite mouthpiece with bitewings ensures that you do not suffer from jaw fatigue by perfectly fitting into your denture. Lastly, the heat exchanger that encircles the valve mechanism dissipated any cold that is results from gas expansion and the ergonomic exhaust tee relays bubbles out of your range of vision.

Scubapro MK25/S600 – Scuba Regulator

Scubapro MK25 S600

The Scubapro MK25/S600 is a product of one of the world’s most iconic brands Scubapro, which is famous for making premier diving equipments. This first and second stage regulator comes with a good number of innovative features.

It is a fully balanced regulator, which assures you of an excellent breathing performance regardless of water temperature, pressure or depth. This regulator is environmentally sealed and it has also been enhanced with coatings and finish on the internal parts for preventing any likelihood of an accidental free-flow. Even when diving in extreme temperatures such as ice diving, the first stage properties of this regulator ensure that the internal parts do not freeze up or malfunction.

When it comes to the second stage, this regulator has an inhalation control that regulates the breathing resistance through turning the control bezel to the side. This simply means that it either decreases or increases the breathing resistance by enabling you to adjust it based on your personal breathing resistance rate.

Read Post  What Is Scuba Diving – Everything You Need To Know

Another great feature of this regulator is the Bench Area Control where there is a pre dive and dive mode indications. By choosing the pre-dive mode, air is allowed back to the diaphragm minimizing the chances of free flow incidences and by choosing the dive mode, optimum air is allowed to flow freely out of the mouthpiece. Finally, the mouthpiece is designed with soft materials minimizes the chances of your jaws getting fatigued and the soft rounded edges ensures that you enjoy a comfortable mouth grip.

Palantic AS101 YOKE Diving – Dive Regulator & Octopus Combo

Palantic AS101 YOKE Diving

The Palantic AS101 YOKE is a premium quality scuba regulator that is designed with great features to give you an amazing breathing performance. The AS101 regulator combo package comes to you in a compact and lightweight setting to ensure that your underwater experience will not be hindered by unnecessary bulkiness.

The first stage regulator employs the use of an unbalanced flow by a piston that has a maximum working pressure of 3500psi. The four low-pressure ports then release the air at a low pressure of between 135psi to 145psi. It also comes with an environmental sealing that protects it against possible freezing in extreme water temperature, corrosion or contamination of internal parts.

When it comes to the second stage regulator, the Palantic AS101 YOKE is highly recommended to beginner divers. They do not need any adjustment on the airflow and all one is required to do is put on the mouthpiece and the air will just flow on demand and you continue inhaling.

This combo package also has its own alternate air source or octopus and a 36 inches yellow colored low-pressure hose. The alternate air source and the main second stage have a large purge button that is ideal especially for beginners since one need to just press on the button and the air will start to flow freely.

Mares MV Octopus – Dive Regulator

Mares MV Octopus

The Mares MV Octopus is a compact and light alternate air source that has been solely designed to be used as an alternative air source and not as a primary or main regulator. Unlike the most common regulators that are circular n shape, this one comes in a unique compact rectangular with soft edges on the sides.

The symmetrical shape of this regulator is for ensuring that it can be used from either the right or the left side. The internal design of this regulator employs the use of the Vortex Assisted Design, that arrange the internal parts in a way that they convey air towards the mouthpiece in rippling vortex of minimal pressure. This way, it forms a highly sensitive airflow that results to lower breathing resistance.

This design however has both a positive and a negative side. The positive thing about it is that the breathing resistance is kept at its lowest regardless of the depth. The negative side of this design is that if the slightest pressure is exerted on the diaphragm, for example, when you do a giant stride entry, it will make the regulator to free flow even when it is not in use or when it is still in the mouthpiece holder. This regulator is nitrox compatible although it should only be used when diving in warm waters and not in extreme temperatures such as ice diving.

Cressi XS Compact AC2 – Best Regulator

Cressi XS Compact AC2

The Cressi XS Compact AC2 is a top scuba regulator that is known for its simple but sturdy features that makes it a low cost maintenance regulator. The first stage regulator is made from the durable marine chromed brass for longevity and durability.

It is also among the most affordable regulators that are currently in the market and an ideal option for the beginner divers. This first stage regulator is highly dependable with a non-balanced flow by piston design.

It is simply designed but yet it is fail-safe and it is able to deliver air even if that is first stage malfunction. The first stage features a single high-pressure port and four low-pressure ports. The first stage also uses a conical filter that has a larger surface area for a higher rate of airflow.

The second stage regulator is made of the durable and non-corrosive high quality polymers, and it has a reliable downstream demand valve mechanism. The airflow is conveyed to the mouthpiece through injection that creates a venturi effect that boosts the regulator’s performance.

The big and soft purge cover enables an easy clearing of the second stage and a silicone mouthpiece for comfortable breathing. Lastly, this regulator is very compact and lightweight adding to your convenience.

Mares Abyss 22 Navy 2 – Best Regulator

Mares Abyss 22 Navy 2

The Mares Abyss 22 Navy 2 is a premier regulator that is designed to match the US Navy standards. It is very robust and sturdy with an ability to withstand even the extreme temperatures such as ice diving. It offers you an outstanding breathing performance even in the toughest water conditions.

The CWD technology prevents water from entering from the spring cavity thus maintaining the airflow. The dynamic flow control system minimizes immediate pressure drop when inhaling so that you continue enjoying a constant air inflow.

The first stage has a balanced diaphragm that is made of chrome plated marine brass that ensures that the regulator is performing at its peak regardless of the depth. In addition, it does not allow any water to get to the inner mechanism. All the inner parts are environmentally sealed to protect them from corrosion and other contaminants.

The second stage features a patented Tri-material Valve Technology that helps the regulator optimize its performance and reliability. The valve is sealed with strong Polyurethane and the durable brass makes the second stage very durable.

The all-metal construction of the second stage prevents it from freezing because of the high thermal conductivity. The patented mesh design reduces the water flow impact even in strong currents and the Vortex assisted Design system creates a swirling vortex when air is channeled to the mouthpiece keeping the diaphragm down during inhalation.

Atomic T3 Titanium Swivel – Sealed Scuba Regulator

Atomic T3 Titanium Swivel

The Atomic T3 Titanium is without any doubts one of the best diving regulators that the market is currently offering. It is made of the strong Titanium that is ultra lightweight and it lasts for a very long time.

This regulator is ideal for use both warm and cold-water conditions and it can handle any kind of diving depth. It is fitted with a great seal system that enhances its anti-freezing ability. It is very compact and thus convenient for traveling and an excellent choice even for the high-end divers.

It comes with an Automatic Flow Control (AFC), it is very dependable and corrosion resistant and it will serve you for a long time. It is freeze protected and it is fitted with a reliable seat system. It is also durable enough to last for a period of three years or an equivalent of three hundred dives.

The first stage balances flow via a piston mechanism that enables the user to dive in any kind of depth. It is also freeze protected with premier quality sealing to prevent any entrance of contaminations in the inner mechanism. It has two high-pressure ports and five low-pressure ports, which are on the swivel turrent for an easy hose routing.

This incredible regulator is constructed using the solid titanium that is corrosion resistant and very light in weight. The second stage is a balances liner flow mechanism that makes breathing so effortless in any kind of a diving experience. The high flow design in this stage lowers the breathing efforts giving you a high and enjoyable breathing performance.

It also has an Atomic Patented Automatic Flow Control that controls the flow of air very efficiently, and the venturi effect makes sure of an optimum breathing resistance at all depths. The mouthpiece is made of durable silicone that is very comfortable in your mouth reducing any jaw fatigue.

The adjustable and over molded knob is soft to take off in situations when the diver experiences a pulling effect. The comfortable swivel provides for 30 degrees movements without any trouble. This regulator is nitrox compatible, adjustable and very convenient making it a great choice for any diver.

Genesis GS2000 – Best Scuba Regulator

Genesis GS2000

The Genesis GS2000 is an amazing regulator that is best known for its comfort and adjustability. This regulator comes with great features for both the first and the second stages. The regulator comes in a simple, yet unique design. It has a flow by piston that balances the first stage air ensuring an exemplary breathing performance at both full and low-pressure tanks pressures.

This balanced flow-by piston design is a ‘fail safe’ internal mechanism that has a dry seal that keeps the delicate inner parts clean and free of contaminants in any kind of a diving environment.

It is also made from the marine grade chrome plated brass for enhanced durability. The first stage regulator features the Dry Air Demand function that enables the regulator to increase the intermediary pressure without the use of oils or grease, as is the case with most regulators.

The first stage is also equipped with two high-pressure ports, three low-pressure ports, and a high capacity inlet filter that ensures a smooth conveyance of air to the second stage. This regulator’s second stage delivers air with minimal effort and the pre-dive or dive switch prevents unwanted free flow and removes sensitivity when surfing or when jumping off a boat but at the same time delivering a great breathing performance when required to.

The second stage regulator is made from non-corrosive ABS/Polycarbonate stainless steel and the breathing resistance can be adjusted for optimum resistance. The mouthpiece is very comfortable and does not cause any jaw fatigue.

Genesis S.K.O. – Dive Regulator

Genesis S.K.O.

The Genesis S.KO is an alternate regulator for scuba diving that has been designed to offer you the great reliability just as the primary regulator. It has a compact design and it comes in a streamlined flat design that helps it fit perfectly and comfortably in either of your hands. It is therefore convenient for any user. It is also made with durable ABS plastic that is also lightweight ensuring that you enjoy a less cumbersome dive.

The bright yellow soft purge cover of the octopus makes its identification very easy. The silicone mouthpiece is long lasting and very comfortable in your mouth so that you do not suffer jaw fatigue. It is tuned or designed to reduce chances of unwanted free flow.

This octopus offers a breathing performance that is comparable to that of a standard main regulator and it comes with sensitivity adjustment for full control. It is very easy to clean and it is a low-cost maintenance gear. The regulator features four low-pressure ports and it has a very dependable downstream main valve.

How Diving Regulators Work

Diving regulators decreases tank force in two stages. The first stage of pressure decrease is from the tank to an intermediate pressure (of 7 to 10 bar), which is more than that of the water pressure around you. The second stage starts from the midway pressure to ambient pressure, which is similar to the water around you. These two stages are important to make your breathing comfortable.

Let us discuss these two stages in details.

First stage regulator

Diving tanks have compressed air, which is of high pressure of around 3000 pounds per square inch (psi). If you breathe directly from the tank, your lungs would collapse due to high pressure. That is why there is a piston or valve in the first stage to reduce this pressure to around 140 psi to disperse it to the hose.

Read Post  How to Write a Bibliography, with Examples

The two major importances of diving regulators are to decrease the pressure level coming from the tank to make it safe to inhale, and it provides air whenever you need it. The control device opens up for air to get into the hose and eventually closes. Whenever you use the air in the tank, the regulator compensates it.

The regulator works like this:

When you breathe, the pressure from the intermediate chamber lowers to a level lower than the water pressure. Hence, the pressure in the water pushes inward, which opens the piston or valve. The open piston joins the high-pressure chamber to the intermediate-pressure chamber where air runs inside it. This raises its pressure to a level equal to the one in the ambient water. As a result, the piston or valve closes and this process repeats itself.

Second stage regulator

The second stage regulator contains a purge button, mouthpiece, exhaust valve and an inner valve joined to its changeable lever. It has a plastic compartment, which has a rubber diaphragm on the outside and it connects to the ambient water pressure.

The second stage works like this:

When you breathe you reduce the pressure in the 2 nd stage to make it same as the one in the ambient-water pressure. As a result, the water-pressure compresses in on the diaphragm-membrane, which shifts the lever.

This shift on the lever makes the inlet-valve to open. Hence, air flows inside the 2 nd stage from the 1 st stage. Accordingly, the air will move to your lungs via the mouthpiece. When you breathe out, the pressure in the 2 nd stage goes beyond the ambient-water pressure. As a result, the increased pressure goes out on the membrane.

The membrane will shift, which will make the lever to take its original location and the inlet-valve will close. When the pressure in the 2 nd stage rises, the exhaust valve will open. The opening will let the breathed out air to get out of the 2 nd stage. This process reoccurs whenever you inhale while diving.

You should clean your diving regulators after every dive to remove debris, silt and salt water. Such elements can hinder proper movements of membranes and valves or even corrode them. This is a precautionary measure that you should take for your regulators to work perfectly.

Types of Diving Regulators- What is the best regulator for scuba diving

Modern diving regulators are designed in different technologies, materials, sizes, shapes and styles. They also come with prices depending on the intended purpose and quality. Professional instructors and dive retailers go for the highly detailed regulators.

It is important that you buy from the online marketplaces or from a specialist dive store so that you can be advised accordingly. There, you can seek more advice about the features of a regulator, their models, styles and how you will benefit from them.

Regulators differ in terms of their performances during the first stage.

Unbalanced regulators

The term implies that the 1 st stage will utilize tank pressure, partially, to open its inner valve. It implies that whenever you use the air inside the tank, you increase the breathing effort needed to unlock the valve. If you are diving at a depth of a hundred feet, your breathing effort will be marginally low but you will not notice it. However, a technical or an advanced diver might notice this difference because of the increased water pressure.

The unbalanced version of a scuba tank regulator is the most commonly used. It is ideal for people who do not dive over 20 meters. It has a DIN or INT feature that will help you to fasten the cylinder.

Balanced regulator

The first-stage styles do open or “crack” without aid from tank pressure. This makes it easy for you to breath all the time when you dive. Since this regulator type seems easy to use, it might be quite costly. However, it is ideal for people who do many activities when they dive or those who go for the deep dives.

Unlike the unbalanced style, the balanced regulator is best for diving more than 20 meters deep. Likewise, it has INT and DIN feature. You can get a balanced regulator designed just for your diving preference. For instance, you can get the one with anti-freeze features and it will be ideal for diving in cold water. Alternatively, you can get a regulator with venture effect. This will make your breathing easy because it will accelerate the air you breathe.

Diaphragm regulator or piston regulators

Diving regulators use piston or diaphragm to lower pressure coming from the tank during the first stage. Their functionalities are almost the same and they are perfect for recreational diving.

However, these two types are different in a few ways

Diaphragm regulators

These have 2 pieces to their valve-opening device – lever in an air-space, and a diaphragm which pushes inward when air-space contracts due to high external pressure. Such styles prevent the regulator from coming into direct contact with water.

As a result, the regs are resistant to water with elements like salt, silt and sand. The designs also can withstand cold because its inner pieces are covered. That is why you will find that many diving instructors use first stage styles because they require minimal care to handle.

Piston regulators

Unlike the diaphragm regulators, the piston ones cannot resist salt, sand, silt and cold as their inner pieces are uncovered. Piston regulators are simple and basic. This makes them ideal for shallow divers.

There will be no worry of damage since shallow divers use piston regulators in clean and warm water. Most importantly, the piston diving regulators are sold with an environmental seal kit, which guides the user on where and when to use them.

Tips for buying diving regulators

Diving safety

There are brands designed to offer high safety levels for diving regulators. Manufacturers ensure that every model of regulator goes through thorough testing.

They put different prices on these regulators depending on their features and styles. You should take time to evaluate the price and these features/styles.

When buying, you should note that expensive diving regulators do not really imply that they are better or safer than the rest. Many aspects determine the price of a regulator. Select the one with the features that are most suitable for your diving needs such as cold water, cave or professional diving.

Unbalanced and balanced regs for shallow or deep diving

Balanced regulators enable divers to inhale continuously and evenly all through, regardless of the elements in the water. This style is ideal for people who dive in serious depths and for technical divers, which makes them quite pricey. If you are one of them, you can consider investing in a balanced scuba regulator.

The unbalanced diving regulators are ideal for shallow divers and those who dive in clean water with little elements. You should not buy this one for deep diving. This is because they inhale unevenly when you share air either when its tank pressure reduces or at depth. However, they are easy to manage and maintain.

Regulator care and maintenance

This makes diaphragm regulators perfect for depth divers because they can withstand all weathers. This aspect of surviving in stiff weather makes diaphragm regulator to last long. On the contrary, diaphragm regulators are quite expensive and require regular service. If you want a regulator to dive in salty or cold water, you can buy a diaphragm type.

Since a piston regular has only a single moving part, it is easy and cheap to service. However, this is disadvantageous because some water enters during the first stage. This means you will take care of it constantly to secure it from deterioration. The regular service and intense care makes a piston dive regulator more durable than a diaphragm one.

Types of diving

Why do you need a scuba tank regulator? Your answer is a guide when selecting the quality and type of regulator that suits your need. If you dive in deep and cold water, a high-end type with additional features would work just fine for you. Alternatively, if you like to dive in clear or warm water you can go for a low-end regulator. Therefore, you should consider your current type of diving and the one you want to participate in the future.

Dive regulator price

Many regulators in the market differ in price and features. This factor goes hand in hand with the type of diving you want. This means a scuba reg with lots of features might cost more, but it will serve you more diligently than one without these features.

Image of What is the best regulator for scuba diving

Frequently Asked Questions for Diving Regulators

Must I buy a diving reg?

Yes. You cannot dive without one because the air in your scuba tank is virtually impossible to inhale if it is not regulated. Sometimes, you can rent a regulator especially if you are a random diver who dives maybe once or twice a year. However, if you are a full diving enthusiast and you like to dive every so often, buying your reg makes more sense than renting.

Can I get infections when I share diving regulators?

Well, in essence, you are asking whether you can share a dive regulator with your family and the answer is yes. Many people are usually worried about infections or diseases that they might acquire in case they share regulators. Well, there are no reported incidences related to infections caused by regulators sharing. Scuba dive regulators do not cause fungal, viral or bacterial infections.

How often should I clean and sanitize my gear?

It is important that you clean your regulator after you are done with your dive in the salty ocean. You should use non-ionic detergent (does not have hydrocarbons) and a scrub brush to clean your scuba regulator. Wash the inner side of the mouthpiece. This will eradicate gross contamination like saliva, seaweed, sand, dirt and mud from your regulator. Consequently, rinse your device with fresh water. Also, clean your regulator before storage.

Will my scuba regulator make me sink?

It is essential to control your buoyancy while diving. When you swim underwater, your body forms lift just like the one an aircraft’s wing creates. That is why you might sink if you pause. Your body requires little buoyancy when we swim continuously. Take deep breaths in case you get neutral buoyancy when swimming to avoid sinking.

What type of dive regulator suits me?

There are many regulators in the market, which makes it challenging for divers to pick the best. Well, you should buy the one that suits your needs. For instance, there are regulators for fun divers and some for professional divers. The best thing to do is to evaluate your needs for diving. You can refer to our buying tips to see the regulator that suits your needs best.

Conclusion

In this post, so many things arise. For example, you may be wondering whether buying a scuba regulator at a price of between $150 and $1000 is advisable while you can rent one at a low price. Well, this depends on your diving needs. One thing you know is that you cannot dive without the best diving regulator. With the information I have provided here, I hope you can now choose the best one. What is the best regulator for scuba diving for a beginner? Pick one here.

Source https://www.liveabout.com/parts-of-a-scuba-diving-regulator-4123025

Source https://www.scuba-diving-smiles.com/scuba-diving-regulators.html#:~:text=The%20job%20of%20the%20scuba%20regulator%20is%20to,in%20stages%20through%20mechanisms%20built%20into%20a%20regulator.

Source https://scubadivinglovers.com/what-is-the-best-regulator-for-scuba-diving/

Leave a Reply

Your email address will not be published. Required fields are marked *
